For industries like seafood, meat processing, and pharmaceuticals, plate ice machines are ideal for keeping goods at optimal temperatures. The thin sheets of ice conform closely to the products, providing superior cooling and preservation, ensuring freshness for longer periods.
Plate ice machines offer customizable features to meet the unique needs of various industries. These machines can be equipped with different plate sizes, ice thickness settings, and production capacities to suit specific applications, whether for food preservation, beverage cooling, or industrial use. The thin, flexible ice produced can be easily adjusted to match cooling requirements and improve efficiency in a range of processes.
The machines are designed with user-friendly controls and automation, making it easy to set up and operate. With minimal maintenance requirements and the ability to handle heavy-duty use, plate ice machines are a versatile and reliable choice for businesses that require flexibility and customization in their ice production.
| Subject | Unit | Technical parameter | |
| Power supply | Voltage/Phase/Frequency | 220V~480V/3P/50~60Hz | |
| Refrigerant | / | R22/R404A/R507A/R448A/R449A/R717 | |
| Capacity | Kg/day | 3000 | |
| Temperature | Ambient temperature | ℃ | 35 |
| Water inlet temperature | ℃ | 20 | |
| Operating power | Operating power of cutter | Kw | 0.55 |
| Operating power of cold water pump | Kw | 0.55 | |
| Warm water pump | Kw | 0.37 | |
| Total running power | Kw | 14.41 | |
| Installment power | Kw | 18 | |
| Compressor | Manufacturer | Bitzer | |
| Refrigeration capacity | Kw | 21.4 | |
| Operating power | Kw | 20.9 | |
| Compressor COP/EER | Kw/kw | 11.84 | |
| Horse power | Hp | 15 | |
| Condenser | Fan power | Kw | 1.1 |
| Cooling way | Air cooling | ||
| Installment | Externally installed | ||
| Dimension | Size of ice maker | L×W×H(mm) | 2200x1500x2000 |
| Size of condenser | L×W×H(mm) | 1300x1500x1450 | |
| Size of water feeding pipe | 1/2" | ||
| Operating weight | Operating weight of plate ice maker | Kg | 1250 |
| Operating weight of condenser | Kg | 89 | |
| Water supply pressure requirement | Bar | 1 | |
